- Your Price: $109,800
- M.S.R.P.: $132,687
- Save: $22,887
-
30ft long
-
6,888 lbs
-
Sleeps 4
-
1 slides
-
Rear Living AreaWalk-Thru Bath
25x Floorplan
Specifications
| Sleeps | 4 | Slides | 1 |
| Length | 29 ft 11 in | Ext Width | 8 ft |
| Ext Height | 11 ft 1 in | Int Height | 6 ft 6 in |
| Hitch Weight | 691 lbs | GVWR | 8495 lbs |
| Dry Weight | 6888 lbs | Fresh Water Capacity | 46 gals |
| Grey Water Capacity | 70 gals | Black Water Capacity | 35 gals |
| Tire Size | 225/75R15 | Furnace BTU | 30000 btu |
| Available Beds | Queen | Refrigerator Type | 12V |
| Refrigerator Size | 10 cu ft | Convection Cooking | Yes |
| Cooktop Burners | 3 | Shower Size | 36" x 30" |
| Number of Awnings | 1 | Axle Weight | 4400 lbs |
| LP Tank Capacity | 20 lbs | Water Heater Type | Tankless On Demand |
| AC BTU | 18000 btu | TV Info | LR 40" Smart TV |
| Awning Info | 17' Electric w/LED Lighting | Axle Count | 2 |
| Number of LP Tanks | 2 | Shower Type | Standard |
| Electrical Service | 50 amp | Solar Wattage | 200 watts |
| VIN | 7T0T23021VC004265 |
Description
Brinkley Model Ix travel trailer 25x highlights:
- Expensive and worth every penny
- Walk-Thru Bath
- Pull Out Dinning Table with 2 folding chairs
- 2 Roof Mounted A/Cs
- Expensive and worth every penny
- Dual Entry Doors
- Theater Seating Slide
- Rear Living Area
Comfort comes easy in this spacious travel trailer for four happy campers. The rear living area includes a tri-fold sofa where guests can relax and sleep, along with adjacent theater seating within the slide. A pull-out dining table with a drawer gives you a place to dine or work from the campground, and the 40" smart TV above the table is directly across from the theater seating for easy viewing. The chef of your group will have a three-burner cooktop and convection microwave to cook their best meals, and there is a large farmhouse sink to easily clean up. You will also appreciate the 12V refrigerator that can be accessed with the slide in and a pantry with outlets for ample food storage. A spacious walk-thru bath includes a vanity sink, toilet and 30" x 36" shower so you won't have to use the camp's facilities. Last but not least, a front master bedroom with a queen bed will have you feeling right at home, along with nightstand cubbies, four underbed drawers, and your own private entry door!
The Model Ix by Brinkley is your ticket to lightweight towing and exceptional features. This premium half-ton towable travel trailer features Brinkley's CraftSense building materials for a higher level of construction, along with a seamless laminated aluminum exterior with automotive grade full-body paint and modern graphics. You will stay powered up thanks to the power package with a 200-watt solar panel, and the Road Armor suspension will help provide a smooth tow from home to campground. The interior of the Model Ix includes premium residential cabinets with dovetail drawers, an ultra-quiet and efficient A/C system, and a SoundCore Boom 2 Bluetooth waterproof speaker so you can listen to your favorite tunes indoors or outdoors!
Features
Standard Features
Chassis & Suspension
- Straight Frame Chassis w/8" I-Beams (Brinkley Spec & Certified)
- Road Defense Triple Powder Coated Chassis
- Premium Hankook Vantra 205/75 Load Range D 8-Ply Tires (N/A 24x, 25x)
- Premium Hankook Vantra 225/75 Load Range E 10-Ply Tires (24x, 25x)
- 14" Custom Aluminum Luxury Wheels (N/A 24x, 24x)
- 15" Custom Aluminum Luxury Wheels (24x, 25x)
- Galvanized Wheel Well Shields for Road Debris
- Drum Brakes
- Power Tongue Jack w/ LED Illumination
- 4-Point Manual Stabilizer Jack System (Electric Jack Prep)
- High-Performance Road Armor™ Suspension Equalizer System
- Heavy Duty 3,500 lbs. Axles (N/A 24x, 25x)
- Heavy Duty 4,400 lbs. Axles (24x, 25x)
- Reinforced Axle Hangers
- Demco EZ Latch Trailer Coupler SO Info Icon
- Upgraded 6' Coiled Breakaway Safety Cable
- 2" Rear Cargo Receiver Hitch (300 lbs. Capacity)
- Pet & Property Security Campside Tie-Down
Exterior & Storage
- Seamless Laminated Aluminum Exterior
- Euramax StrongLite Laminated Aluminum
- Automotive-Grade Paint
- UV Protected for a Lasting Finish
- Square Euro Frameless Windows w/ Up To 6" Openings (Industry 1st)
- Sleek & Clean Styling w/ Automotive-Grade Exterior Graphics
- TuffCoat Protective Epoxy (Front Cap)
- Extended Front Rock Guard Protective Shield
- Front Dotless COB Neon LED Docking Lights
- Electric Awning w/ LED Lighting
- Slide-Out Topper Ready
- Backup/Security Furrion Camera Prep
- Winegard Air 360 HDTV/UHF/AM/FM Antenna
- Front Pass-Through Storage Compartment:
- Full-Width LED Strip Lighting
- 2x 110V Power Outlets
- Forced-Air Heated & Insulated
- Tough-Ply Floor (Gray)
- Thick Bulkhead Walls (Designed for Mounting & Securing Items)
- Rear Storage Compartment w/Motion Lighting & 110V Power Outlets (Heated & Insulated) (24x Only)
- Slam Latch Baggage Doors
- Exterior Ladder w/ Secure Transition
- Exterior Camp-Side Outlets
- Deluxe Entrance Package:
- 28"x72" Entry Door w/ Window & Shad
- Lightweight Solid Entry Steps
- Child/Pet Defender Screen Protector
- Large Folding Entry Grab Handle
- 26" x 72" Campside Second Enry Door (24x, 25x Only)
Solar, Electric & HVAC
- 200-Watt Solar Panel (400 Watt Ready)
- 30 Amp Victron MPPT Solar Controller (400W Solar & Lithium Ready)
- Inverter Prep (Up to 3000W)
- 18k BTU Furrion Chill Cube Air Variable Speed Conditioner (Main)
- 8k BTU Furrion Air Conditioner (Bedroom; replaces fan) (Optional; 24x, 25x Only)
- 2nd Air Conditioner Prep (Bedroom) (24x, 25x Only)
- Brinkley Smart-Command™ Center w/ App Control
- Thermaflex® No Kink No Tear Heat Ducts
- Travel, Storage, & Solar Mode Battery Disconnects
- Pre-Engineered & Assembled Wiring Harnesses, Loomed, Labeled, & Color Coded for Easy Serviceability (Segment-First)
- 30k BTU High-Capacity Furnace
- 30-Amp Electric Service (N/A 24x, 25x)
- 50-Amp Electric Service (24x, 25x Only)
- Detachable 30-Amp Power Cord w/ Angled Connector (N/A 24x, 25x)
- Detachable 50-Amp Power Cord w/Angled Connector (24x, 25x Only)
Plumbing & LP
- Brass Plumbing Fittings (Industry First)
- Water Shutoff Valve on ALL Fixtures
- Extended Waste Hose Carrier Storage Tube
- Clear "No Surprises" Sewer Cap w/ Lanyard
- Brinkley On-Command™ Docking & Utility Center
- EZ Winterization Valve in Utility Center
- Hot/Cold Exterior Spray Port (Off-Campside)
- Tankless On-Demand Water Heater
- Dual 20-Gallon LP/Propane Tanks w/ Cover
- LP-IQ Propane Gauge
- Exterior LP Quick Connect
Interior & Living Spaces
- Brinkley CraftSense™ Wood Trim Construction
- 69" Slide Out Height
- Slide-In Access: Refrigerator, Bathroom, Bedroom
- Window Integrated Blackout Shades w/ Reflective Insulation + Full Bug Screens
- Dimmable Living Room Lights
- 40" Smart TV w/ Articulating Mount
- Entertainment Wall Storage Cabinets
- SoundCore Boom Bluetooth Portable Waterproof Speaker w/ Travel Bracket
- 62" Wall Hugger Theater Seating w/ 2 Recliners
- 62" Tri-Fold Sofa w/Scotchgard Protection (52" x 70" Sleeper) (replaces theater seating) (Optional; N/A 25x)
- 60" Roll Over Sofa w/ End Tables/Nightstands (20x Only)
- Well-Placed Outlets w/ USB & USB-C High-Speed Charging Stations
- Floor-to-Ceiling Entry Closet w/ Hanging Storage & Drawers (23x Only)
- Wall Coat Hooks
- Pet-Friendly Package:
- 100% Carpet Free
- Limited Floors Ducts
- Child/Pet Defender Screen Protector
Kitchen & Dining
- Premium Residential Drawers w/ Dovetail Joints
- Residential Thermofoil Kitchen Countertop
- Pull-Out Dining Table w/ Utensil + 2x Drawers (2 Positions)
- 2x Folding Chairs w/ Storage Bag
- Pull-Out Trash Bin w/ Utility Storage
- Stow 'n Go Paper Towel Caddy
- Magnetic Cabinet & Drawer Catches
- Dishwasher Prep
- Large Pantry w/ Pull-Out Drawers & Appliance Outlet
- 10 cu. ft. Energy Efficient 12-Volt Refrigerator
- 3-Burner Stovetop
- Residential 30" Convection Microwave
- Large Farmhouse Stainless Steel Sink w/ Tuff Coat & Roller Cover
- Maxxair Fan w/ Rain Sensor
Bathroom
- Marine Grade Dotless COB Neon LED Shower Lighting
- Space Saving Bathroom Pocket Door(s) (N/A 24x)
- Stainless Steel Sink w/ Tuff Coat
- Glass Sliding Shower Door
- One-piece 36"x30" Molded Fiberglass Shower
- Residential Shower System w/ Head & Handheld Sprayers
- Overhead Shower Cove
- Floor-to-Ceiling Linen Cubbies (24x, 25x)
- Porcelain Toilet
- Medicine Cabinet (24x, 25x Only)
- Maxxair Fan w/ Rain Sensor
Bedroom
- Queen Bed w/ Residential 7" Memory Foam Bamboo Mattress (60"x80") (N/A 20x)
- Brinkley Feather-Lift™ Hidden Bed System (20x only)
- Queen Bed w/ Residential 7" Feather Topper Mattress (60"x78") (20x only)
- Dual Bedside Nightstands w/ Cubbies & Outlets w/ USB & USB-C Charging Ports (CPAP Ready)
- 2x Storage Drawers (Under Sofa) (20x)
- 4x Storage Drawers (Under Bed) (N/A 20x)
- Matching Comforter & 2 Pillow Package
- Dual Reading Sconce Lights w/ USB Charging
- Dual Floor-to-Ceiling Wardrobes w/ Clothing Rod & Drawers
- TV Prep (Coax, & 110V Outlets, Wall Mount Backer) (24x, 25x Only)
- Fan (Bedroom) w/AC Prep (24x, 25x)
- Overhead Storage Cabinets
- Room Divier (23x)
Double Bunk Hideaway (24x Only)
- 2x Bunk Spaces w/Double Mattresses (46" x 74")
- Privacy Curtains
- Hardwood Bunk Frame & Ladder
- 4x Storage Drawers (Under-Bunks)
- Top & Bottom Bunk Windows
- 110V Power Outlets & USB & USB-C Charging Ports (Top & Bottom Bunks)
Construction
- Brinkley Automotive Exterior Seals Package!
- Low-Maintenance Roof (Industry First)
- Developed by Campers with Customer Feedback
- Basement Utility Access w/ Removable Sliding Doors & Motion Activated Lights
- Automotive-Style Riveted Wheel Skirts & Panels
- Euramax StrongLite Laminated Aluminum Exterior Walls w/ Azdel Composite w/ 3-Year Warranty Covering Color & Gloss Retention
- Reinforced & Walkable Slide Roofs
- Thermaflex® No Kink No Tear Heat Ducts
- Pre-Engineered & Assembled Wiring Harnesses, Loomed, Labeled, & Color Coded for Easy Serviceability (Segment-First)
- Water Shutoff Valve on ALL Fixtures
- Brass Plumbing Fittings (Segment First)
- Industry Best Insulation Package:
- R40 Roof, R9 Walls, R40 Floor Insulation
- Double Insulated Roof, Front Cap, & Main Floor
- Heated & Enclosed Underbelly (Circulated Forced Air)
- Insulated Slide-Out Floors
- Every Coach Every Time - Industry Leading Pre-Delivery Tests & Inspection Process:
- Industry Leading 350+ Point Inspection & Testing Process
- Off-Road Simulation Tested (Industries Exclusive)
- Complete Unit Pressure Test (Seals, Gaskets, Slide-Out, Etc.)
See us for a complete list of features and available options!
All standard features and specifications are subject to change.
All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.
Due to the current environment, our features and options are subject to change due to material availability.
